LDG series single cone screw vacuum drying - main structure

Single cone screw vacuum drying is composed of motor, reducer, frame, mechanical seal, metal sintering mesh filter, hollow twin screw stirrer, cone cylinder with jacket heating and discharge valve and other components.

1.  Transmission and sealing parts:

It consists of a motor, a reducer, a frame and a mechanical seal.

1.1 Motor: the frequency conversion speed regulating motor is adopted, and the speed can be adjusted as required during operation.

1.2 Reducer: SLFA series helical gear reducer, stable and reliable operation, low noise, long service life.

1.3 Rack: self-designed, high manufacturing accuracy.  Equipped with two pairs of roller bearings, adjustable agitator height and radial swing.

1.4 Mechanical seal: single end face sanitary type with material receiving flushing chamber, good sealing performance.

2.  Beater:

The hollow stirring shaft is respectively connected with the hollow screw belt with the support rod, and the upper and lower ends of the hollow screw belt are connected with the hollow support rod to form a loop through the heat medium.  In order that the material does not stick to the cylinder wall, the gap between the screw belt and the cylinder wall is very small.
